Thermal Imaging Scope - XQ23V
Manufacture ID: PL77337
Thermal imaging scopes Quantum based on IR sensor (uncooled microbolometer) are represented by a number of models featuring various frame rate, magnification and lens diameter . The scopes are designed for the use both in the nighttime and in the daylight in inclement weather conditions (fog, smog, rain) to see through obstacles hindering detection of targets (branches, tallgrass, thick bushes etc.). Unlike the image intensifier tube based night vision devices, thermal imaging scopes Quantum do not require an external source of light and are not af fected by bright light exposure. Thermal imaging scopes Quantum have a wide range application including night hunting, observation and terrain orientation, search and rescue operations.
Features:
- 384x288 resolution, 17um pixel pitch core
- 50hz refresh rate
- 2 second start up time
- Multiple color viewing modes
- Stadiametric rangefinder
- Automatic shutoff
- Up to 875 yd detection range
- Manual, automatic, and semi automatic calibration modes
- City, forest, and identification viewing modes
- Defective pixel repair feature
- OLED display
- Video output for recording
- External power supply adaptable
- Variable magnification of 1.8-7.2
- Silent calibration
Includes:
- Carrying case
- Manual
- Video output/power cable
- Hand strap
- External battery container
- Lens cleaning cloth
- 4xAA batteries
Specifications:
- Frame Rate, Hz: 50
- Battery Type: 4xAA
- Power Supply: 4-6V
- Colors: 7
- External Power Supply: DC 8.4/16
- Battery life, (with video out off), hours: 6.5
- Focusing Lens, Eye/Obj/Int: Internal
- Diopter Adjustment: +5 to -5
- Diameter, Exit Pupil: 5mm
- Material, Lens: Germanium, glass
- Body Material: Glass-nylon composite
- Height: 2.3"
- Width: 3.4"
- Length: 7.9"
- Operating temperature, F/C: -13 to 122 / -25 to 50
- Range of Detection, yd / m (Object (Human = 1.7*0.5m): 875/800
- Remote Control: Yes
- Calibration: Manual, automatic, and semi-automatic
- Tripod Mount: 2x1/4
- Eye Relief, mm: 16
- Distance, Minimum Focusing Distance: 3m
- Pin Type of Video Input / Output: Special
- Video IN / OUT Availability: No/Yes
- Display Resolution, pix.: 640x480
- Display Type: AMOLED
- Pixel Pitch, em: 17
- Spectral Sensitivity, em: 8-15
- Sensor response: LWIR
- Microbolometer Resolution, pixels: 384x288
- Operating modes: City, forest, and identification
- Defective Pixel Repair Option: Yes
- Field of View, m@100m, horizontal: 29-21.8
- Field of View, e, horizontal * vertical: 16.5-12.4
- Relative aperture, D/f': 1:1.4
- Lens Focus, mm: 22.5
- Diameter, Lens, mm: 18
- Digital Zoom: 2x/3x/4x
- Optical Characteristic, Smooth digital zoom, x: 1.8-7.2
- Magnification: 1.8
- Weight (without batteries): 12.3 oz.
